    Low Noise Denso Electric Wiper Motor 12V DC 45W for Fiat Palio Easy Install

    Ask Lasest Price
    Brand Name : CIROLLA
    Model Number : 1044
    Certification : CE/CCC/ SGS
    Price : Negotiation
    Payment Terms : T/T,L/C, Western Union
    Supply Ability : 50,000pcs/month
    Delivery Time : 25-30days
    • Product Details
    • Company Profile

    Low Noise Denso Electric Wiper Motor 12V DC 45W for Fiat Palio Easy Install


    Low Noise Denso Electric Wiper Motor 12V DC 45W for Fiat Palio Easy Install​


    Description:


    A windscreen wiper or windshield wiper is a device used to remove rain and debris from a windscreen or windshield. Almost all motor vehicles, including trains, watercraft and some aircraft, are equipped with such wipers, which are usually a legal requirement. A gear motor is driving device of the wiping system.


    Applications:


    Automotive mini wiper motor widely used for all kinds of cars, trucks and buses


    For Fiat Palio


    Denso: TGE 64343418


    Specifications:

    Wiper Motor Performance Data:


    Type

    Brush

    Voltage

    12VDC

    Power

    30W

    No-load Speed

    50rpm

    No-load Current

    1.1A

    On-load Speed

    35rpm

    On-load Current

    4.4A

    Stall torque

    20Nm

    Gear material

    Nylon

    Protection class

    IP44

    Rotate direction

    CW and CCW

    Weight

    1.5kg


    Wiper Motor Characteristic curves:



    State

    Voltage

    Current

    Pin

    Torque

    Speed

    Pout

    Eff

    V

    A

    W

    N.m

    rpm

    W

    %

    Speed_max

    12.12

    1.138

    13.79

    0.25

    49.7

    1.30

    9.4

    Eff_max

    12.12

    4.398

    53.30

    5.05

    36.7

    19.40

    36.4

    Pout_max

    12.11

    8.027

    97.27

    10.69

    24.1

    26.97

    27.7

    Torque_max

    12.11

    13.81

    167.3

    19.08

    0.1

    0.19

    0.1

    End

    12.11

    13.81

    167.3

    19.08

    0.1

    0.19

    0.1

    Wiper Motor Outline drawings:



    Competitive Advantage:


    Designed to rotate 90° compared to the 110° operation of a conventional motor, the action of the 'Reversing' motor reduces the travel of the wiper linkage and releases space in the plenum area. Electronic control of the wiper motor offers new features such as 'Special Park', automatic wiping angle control, speed control, obstacle detection.
