Mini Automatic Sliding Gate Motor Waterproof with Worm Gearbox High Torque

    Buy cheap Mini Automatic Sliding Gate Motor Waterproof with Worm Gearbox High Torque from wholesalers

    Buy cheap Mini Automatic Sliding Gate Motor Waterproof with Worm Gearbox High Torque from wholesalers
    • Buy cheap Mini Automatic Sliding Gate Motor Waterproof with Worm Gearbox High Torque from wholesalers

    Mini Automatic Sliding Gate Motor Waterproof with Worm Gearbox High Torque

    Ask Lasest Price
    Brand Name : CIROLLA
    Model Number : 3095
    Certification : CE/CCC/ SGS
    Price : Negotiation
    Payment Terms : T/T,L/C, Western Union
    Supply Ability : 50,000pcs/month
    Delivery Time : 25-30days
    • Product Details
    • Company Profile

    Mini Automatic Sliding Gate Motor Waterproof with Worm Gearbox High Torque


    Mini Automatic Sliding Gate Motor Waterproof with Worm Gearbox High Torque


    Description:


    Worm gear Motor is power supply of Electric Sliding Gate Motor,A gate operator is a mechanical device used to open and close a gate, such as one at the end of a driveway. As its name implies, a slide gate either slides on wheels from left to right or right to left, not unlike many department store automatic doors. Electric Slide gate operators are commonly installed at the end of the gate in the closed position but can also be installed by the end of the gate in the open position.


    Specifications:

    Motor Performance:


    Motor Type

    Brush

    Voltage

    24VDC

    Power

    70W

    No load Speed

    150rpm

    No load Current

    1.3A

    On load Speed

    125rpm

    On load Current

    3.0A

    Work torque

    3Nm

    Stall torque

    12Nm

    Gear material

    Nylon

    Protection class

    IP44

    Weight

    1.5kg


    Motor Characteristic curves:



    Applications:


    This kind of brushless dc motor can be widely used for Electric Sliding Gate Openers


    Competitive Advantage:


    Automatic Safety Reverse – Garage Ace sensors when someone or something is in the way, and reverses automatically.

    Manual Override - Motor can be easily disengaged in the event of power failure for manual operation of door.

    Handy Wall Switch - Door can be operated from switch on interior mounted control box independently of remote transmitter.

    Automatic Run Time - If motor is activated while disengaged, the auto run time will turn motor off after 30 seconds

    DIY Installation - Step-by-step instructions will guide you through installation. the opener can be installed on the left or right-hand side of the door.

    Quiet Operation - No need to let the neighborhood know when you come and go!

    Safe and Secure - High security rolling code transmitters. Two remotes supplied.

    Courtesy light -Comes on automatically when the door is in use. The light will stay on for approximately 3 minutes, then turns off automatically.


    Motor Outline drawings:
