Round Electric Sliding Glass Door Motor Heavy Duty 24V DC Brushless​

Quick Detail:

Code: 413 Type: Brushless Operation Voltage: 24VDC Power: 75W Rotate Direction: CW &CCW

Application: Automatic door Door Open style: Sliding Opening type: With Remote Control

Functional: Automatic operation/hold-open/closed/half-open

Security: Automatic stop/reverse during opening or closing

Door Weight Bearable: 300kg /2 Leaves Door Width: 650~1600mm

Environment temperature: -10 ~ +55ºC Lifetime: 6 million times

Description:

Automatic door system is totally micro-computer optimized. Door leaf position setting and adjustment, slide distance setting and adjustment, door leaf opening/closing speed setting and adjustment is accurately controlled by microcomputer controller.

Brushless motor provides power for automatic sliding doors, with silent operation, has big torque, long service life and high efficiency. It adopts European technology to integrate motor with gear box, which offers strong driving and reliable operation and increased power output, it can adapt to a large doors. Helical gear transmission in the gear box ensures the stable and reliable operation, even used for heavy door, the whole system operates easily.

Applications:

Electric sliding door motor can be used on any kinds of Automatic doors: Sliding Door, Swing Door, Curved Door, Folding Door, Hermetical Door, Telescopic Door, Panic Door, Revolving Door, and Hospital, which are widely used in Hotel, Hospital, Shopping Mall, Bank, Commercial office building, etc.

Specifications:

Performance data of Electric Sliding Door Motor:

Outline drawings of Electric Sliding Door Motor:

Electric Sliding Door Application Examples:

Cirolla Motor Co., ltd is leading manufacturer of DC motors. Our motors are widely used in the filed of Automatic door system, Health& Medical equipments, Automation machinery, Automobile and Aerospace industry.

We have nearly 20years history of designing& producing PMDC motor and BLDC motors. Our technology are fully developed in traditional brush gear reduction motor,   Presently we are investing more into the production of brushless motors, which is high efficiency, low noise, stable reliability and long life time.

Our company is qualified by ISO 9001:2008 & IS16949 and audited by TUV &SGS. Our motors are CE approved by EC declaration of EMC and LVD conformity. Our annual output is 300,000-50,000sets.

Our motors are exported to worldwide markets, mainly in Europe, North &South America, South-east Asia and Australia. We supply ODM & OEM service to the world's clients. We look forward to producing higher efficiency, quieter, green motors for the world!
